ET6353

  • 产品信息

Die cast aluminum casing.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosive electrostatic powder coating

Stainless steel external screws and mounting plate.

Special surface treatment is required for special coastal environments.

Structurally waterproof, detachable for easy replacement of LED, lens, and driver


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET6353 6W 60° / 60° 2700K / 3000K / 4000K / 5000K 98lm ON / OFF 5 80 LEDx2 220V-240V 1.2Kg
  • 规格
  • 下载
  • 配件

ET6353

Electrical and Control

Voltage220V-240V
Power6W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCREE
LED QuantityLEDx2
Beam Angle60° / 60°
Delivered Lumen98lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.2KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET6353

文件

ET6353

可选配件

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
下载

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
