ET7031

  • 产品信息

Die casting aluminum body and faceplate.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

External screws are all made of stainless steel materials.

The projecting angle can be 90°adjusted .

Marine grade treatment is available for seaside environments.

Structure waterproof, all components can be disassembled and replaced.

Moisture-prevention designed inside.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET7031 72W 10° / 20° / 50° / 90° / TYPE III 2700K / 3000K / 4000K 5222lm（3000K 20°） ON / OFF 5 80 LEDx40 100V - 240V 6.7KG
  • 规格
  • 下载
  • 配件

ET7031

Electrical and Control

Voltage 100V-240V
Power72W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 40
Beam Angle10° / 20° / 50° / 90° / TYPE III
Delivered Lumen6974lm (3000K 20°)
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight6.7KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE
