ET7481

  • 产品信息

Die casting aluminum body and faceplate.

Ultra white tempered glass. Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

External screws are all made of stainless steel materials.

The projecting angle can be 90°adjusted .

Marine grade treatment is available for seaside environments.

Structure waterproof, all components can be disassembled and replaced.

Moisture-prevention designed inside.



型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET7481 20W 8° / 12° / 22° / 35° / 45° / 15°*40° 2700K / 3000K / 4000K 1810lm（3000K 12°） ON / OFF 5 80 LED*16 100V - 240V 2KG
  • 规格
  • 下载
  • 配件

ET7481

Electrical and Control

Voltage100V-240V
Power20W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 16
Beam Angle8° / 12° / 22° / 35° / 45° / 15°*40°
Delivered Lumen1810lm（3000K 12°）
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE


ET7481

文件

ET7481

ET7481

可选配件

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
下载

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
