ET7731

  • 产品信息

Wing, a high-power, multi application, multi combination and multi specification circular floodlight. Self-circulating air convection structure maximally improve the heat dissipation

efficiency of the lamp. Internal anti glare hood to reduce glare.

The lamp with no exposed cable can adjust the projection direction vertically and horizontally.

Die cast aluminum casing.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Detachable structural waterproof process ensures sustainable usage and reduces maintenance costs.

Suitable for building facade precise lighting and poles multi-directional lighting in public places.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET7731.RGBW 80W 7° / 15° / 25° / 45° / 60° / 15°*30° 2700K / 3000K / 4000K / 5000K 2661lm(3000K 15°) DMX512 3 80 LEDx9 100V-240V 5.2KG
ET7731 86W 5° / 15° / 24° / 36° / 50° / 20°*50° 2700K / 3000K / 4000K / 5000K 7043lm(3000K 15°) ON / OFF 3 80 COBx6 100-240V 5.2KG
  • 规格
  • 下载
  • 配件

ET7731.RGBW

Electrical and Control

Voltage 100V-240V
Power80W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 9
Beam Angle7° / 15° / 25° / 45° / 60° / 15°*30°
Delivered Lumen2661lm(3000K 15°)
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight5.2KG
Warranty3 years
RatingIP66
Impact ProtectionIK08
CertificationsCE



ET7731.RGBW

文件

ET7731.RGBW

可选配件

  • 规格
  • 下载
  • 配件

ET7731

Electrical and Control

Voltage 100V-240V
Power86W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 6
Beam Angle5° / 15° / 24° / 36° / 50° / 20°*50°
Delivered Lumen7043lm(3000K 15°)
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight5.2KG
Warranty3 years
RatingIP66
Impact ProtectionIK08
CertificationsCE



ET7731

ET7731

可选配件

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
下载

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
