ET2211

  • 产品信息

Die casting aluminum body and faceplate.

Ultra white tempered glass.

Silicone gasket.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Strengthened PP or SS preinstall box.

Design of structural heat dissipation.

On/off standard and 0-10V.

The light can be installed on pillar, wall or side of stais according to it's size.

Can be used to indicate or light on small path or ground area, no risks to  public for it's recessed mounting design.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET2211 12W 360° 2700K / 3000K / 4000K 780lm ON/OFF 5 80 LEDx5 100V-240V 0.8Kg
  • 规格
  • 下载
  • 配件

ET2211

Electrical and Control

Voltage 100V-240V
Power12W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.3M H05RN-F 3x1mm2
Environmental                                                                                        -20 °C ~ 50 °C


LED and Optics

LED Brand CREE
LED QuantityLED X 1
Beam Angle360°
Delivered Lumen780lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.8KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE
