ET2005

  • 产品信息

The professional structure and optical lighting design provide a comfortable lighting environment while meeting the lighting needs.

 Die cast aluminum casing.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Detachable structural waterproof process ensures sustainable usage and reduces maintenance costs.

Suitable for villas, park trails, garage entrances and exits, etc. platform, etc.



型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET2005 12W 360° 2700K / 3000K / 4000K 365lm ON/OFF 5 80 SMDx24 180V-264V 1.5Kg
  • 规格
  • 下载
  • 配件

ET2005

Electrical and Control

Voltage180V-264V
Power12W
Power SupplyRemote
ControlON/OFF / 0-10V / DALI
Cable0.3M H05RN-F 3x1mm2
Environmental                                                                                        -30 °C ~ 50 °C


LED and Optics

LED BrandOSRAM
LED QuantitySMDx24
Beam Angle360°
Delivered Lumen365lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.5KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET2005

文件

ET2005

ET2005

可选配件

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
下载

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
