ET2002

  • 产品信息

The professional structure and optical lighting design provide a comfortable lighting environment while meeting the lighting needs.

 Die cast aluminum casing.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

Detachable structural waterproof process ensures sustainable usage and reduces maintenance costs.

Suitable for villas, park trails, garage entrances and exits, etc. platform, etc.



型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET2002 4W 360° 2700K / 3000K / 4000K 100lm ON/OFF 5 80 SMDx6 24VDC 0.4Kg
  • 规格
  • 下载
  • 配件

ET2002

Electrical and Control

Voltage DC24V
Power4W
Power SupplyRemote
ControlON/OFF / 0-10V / DALI
Cable0.3M H05RN-F 3x1mm2
Environmental                                                                                        -40 °C ~ 50 °C


LED and Optics

LED BrandOSRAM
LED QuantitySMDx6
Beam Angle360°
Delivered Lumen100lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.4KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET2002
