ET9303

  • 产品信息

Underwater Wall Washer Lights

Stainless steel body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws and mounting bracket.

Specialized anti-water&vapour wiring.

Design of structural waterproof, durable and long lifetime.



型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET9303 18W 8° / 15° / 30° / 45° / 60° / 10°*60° 2700K / 3000K / 4000K / 5000K 882lm(3000K 8°) ON/OFF 5 80 LEDx12 12VDC 5.2Kg
  • 规格
  • 下载
  • 配件

ET9303

Electrical and Control

Voltage12VDC
Power18W
Power SupplyRemote
ControlON/OFF / 0-10V / DALI
Cable1M H05RN-F 3x1mm2
Environmental                                                                                        -40 °C ~ 50 °C


LED and Optics

LED BrandCREE
LED QuantityLEDx12
Beam Angle8° / 15° / 30° / 45° / 60° / 10°*60°
Delivered Lumen882lm(3000K 8°)
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingStainless steel material
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight5.2KG
Warranty3 years
RatingIP68
Impact ProtectionIK09
CertificationsCE


ET9303

文件

ET9303.IES
