ET9220

  • 产品信息

Recessed Underwater luminaires

Stainless steel body and cover .

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws.

Design of structural waterproof, durable and long lifetime.

Strengthened PP mounting sleeve .

型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET9220 30W 10° / 15° / 25° / 45° / 15°*40° 2700K / 3000K / 4000K / 5000K 1629lm(3000K 10°) ON/OFF 5 80 LEDx18 12VDC 5Kg
  • 规格
  • 下载
  • 配件

ET9220

Electrical and Control

Voltage12VDC
Power30W
Power SupplyRemote
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental                                                                                        -40 °C ~ 50 °C


LED and Optics

LED BrandCREE
LED QuantityLEDx18
Beam Angle10° / 15° / 25° / 45° / 15°*40°
Delivered Lumen1629lm(3000K 10°)
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingStainless steel material
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight5KG
Warranty3 years
RatingIP68
Impact ProtectionIK09
CertificationsCE





ET9220
