ET9054

  • 产品信息

Recessed Underwater luminaires

Stainless steel body and cover .

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws.

Specialized anti-water&vapour wiring.

Design of structural waterproof, durable and long lifetime.

Strengthened PP mounting sleeve .



型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET9054 4W 10° / 15° / 25° / 45° / 15°*35° 2700K / 3000K / 4000K / 5000K 281lm(3000K 10°) ON/OFF 5 80 LEDx3 12VDC 1.2Kg
  • 规格
  • 下载
  • 配件

ET9054

Electrical and Control

Voltage12VDC
Power4W
Power SupplyRemote
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental                                                                                        -40 °C ~ 50 °C


LED and Optics

LED BrandCREE
LED QuantityLEDx3
Beam Angle10° / 15° / 25° / 45° / 15°*35°
Delivered Lumen281lm(3000K 10°)
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingStainless steel material
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.2KG
Warranty3 years
RatingIP68
Impact ProtectionIK09
CertificationsCE



ET9054

文件

ET9054.IES

ET9054

可选配件

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
下载

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
