ET9342

  • 产品信息

Recessed Underwater luminaires——Asymmetric optics

Using a specially designed multiple reflection principle,

the light is efficiently emitted in an asymmetric direction to achieve uniform wall cleaning and anti glare effects.

The product is suitable for installation in key lighting applications such as corridors, walls, and sculptures.

Stainless steel body.

Stainless steel decorative bezel.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws.

Strengthened PP mounting sleeve.

型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET9342 15w 360° 2700K / 3000K / 4000K / 5000K 769lm ON/OFF 3 80 COBx1 12VDC 3.8Kg
  • 规格
  • 下载
  • 配件

ET9342

Electrical and Control

Voltage12VDC
Power15W
Power SupplyRemote
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental                                                                                        -40 °C ~ 50 °C


LED and Optics

LED BrandCREE / CITIZEN
LED QuantityCOBx1
Beam Angle360°
Delivered Lumen769lm
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingStainless steel material
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight3.8KG
Warranty3 years
RatingIP68
Impact ProtectionIK09
CertificationsCE




ET9342

文件

ET9342

可选配件

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
下载

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
