ET8320

  • 产品信息

Trimless round in-ground uplighter

Stainless steel body.

Tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws .

Strengthened PP mounting sleeve .

High Power LED chips, constant current driver, line voltage input.

On/off standard, DALI , 0-10V or Traic dimming is optional.

Specialized anti-water&vapour wiring.

型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET8320 2W 100° 2700K / 3000K / 4000K / 6000K 38lm ON/OFF 7 80 SMDx6 24VDC 0.4KG
  • 规格
  • 下载
  • 配件

ET8320

Electrical and Control

Voltage24VDC
Power2W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantitySMD X 6
Beam Angle100°
Delivered Lumen38lm
Colour RenderingCRI 80
SDCM7
CCT2700K / 3000K / 4000K  6000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.4 KG
Warranty3 years
RatingIP68
Impact ProtectionIK10
CertificationsCE


ET8320

文件

ET8320.IES

ET8320
