ET8316

  • 产品信息

Trimless round in-ground uplighter

Stainless steel body.

Tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws .

Strengthened PP mounting sleeve .

High Power LED chips, constant current driver, line voltage input.

On/off standard, DALI , 0-10V or Traic dimming is optional.

Specialized anti-water&vapour wiring.



型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET8316 2W 10°/15°/22°/45°/60°/15°*55° 2700K / 3000K / 4000K / 5000K 150lm（3000K 15°） ON/OFF 5 80 LEDx1 24VDC 0.3KG
  • 规格
  • 下载
  • 配件

ET8316

Electrical and Control

Voltage24VDC
Power2W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 1
Beam Angle10°/15°/22°/45°/60°/15°*55°
Delivered Lumen150lm
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.3 KG
Warranty3 years
RatingIP68
Impact ProtectionIK10
CertificationsCE


ET8316

文件

ET8316.IES
