ET8829

  • 产品信息

In-ground luminaires——Trimless SS

Trimless design, good concealment, all stainless steel material.

The product is suitable for landscape lighting such as squares, corridors,  steps, water pools sculptures, etc.

Stainless steel body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Stainless steel external screws.

Moisutre-prevention designation.

型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET8829 10W 15°/24°/36°/50°/25°*45° 2700K / 3000K / 4000K / 5000K 825lm ON/OFF 3 80 COBx1 24VDC 2.5KG
  • 规格
  • 下载
  • 配件

ET8829

Electrical and Control

Voltage24VDC
Power10W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1
Beam Angle15°/24°/36°/50°/25°*45°
Delivered Lumen825lm
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2.5 KG
Warranty3 years
RatingIP68
Impact ProtectionIK10
CertificationsCE


ET8829

文件

ET8829.IES

ET8829

可选配件

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
下载

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
