Trimless design, good concealment, all stainless steel material.
The product is suitable for landscape lighting such as squares, corridors, steps, water pools sculptures, etc.
Stainless steel body.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Stainless steel external screws.
Moisutre-prevention designation.
IP68 protection, professional outdoor design for cable configuration with water and moisture resistance.
Can not be used on lanes subjected to horizontal stress caused by acceleration, braking, and/or directional changes.
The pre-installa box needs to be flush with the decorative surface.
The wiring connectors between the main power supply and the lighting fixtures must be waterproof.
To achieve IP68 waterproof rating to prevent circuit instability caused by water leakage.
Sucker is needed to take the fixture out from mounting sleeve.
| 型号 | 功率 | 角度 | 色温 | 流明 | 控制方式 | 色容差 | 显色指数 | LED | 电压 | 重量 |
|---|---|---|---|---|---|---|---|---|---|---|
| ET8827 | 2W | 10°/15°/22°/45°/60°/15°*55° | 2700K / 3000K / 4000K / 6000K | 141lm(3000K 15°) | ON/OFF | 5 | 80 | COBx1 | 24VDC | 0.5KG |
Electrical and Control
| Voltage | 24VDC |
| Power | 2W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -40 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | COB X 1 |
| Beam Angle | 10°/15°/22°/45°/60°/15°*55° |
| Delivered Lumen | 141lm |
| Colour Rendering | CRI 80 |
| SDCM | 5 |
| CCT | 2700K / 3000K / 4000K / 6000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 0.5 KG |
| Warranty | 3 years |
| Rating | IP68 |
| Impact Protection | IK10 |
| Certifications | CE |
