ET8575

  • 产品信息

Trimless design, evenly lighting distribution. Capable to get multiple colors and

patterns.

Suitable for the surrounding square, road guidance, combination patterns and other

land scape cultural travel light art display.

Stainless steel body.

Epoxy resin waterproof luminescent surface.

Stainless steel mounting sleeve.

Moisture-prevention designation, 24VDC power supply


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET8575 4.5W 120° 2700K / 3000K / 4000K / 5000K 50lm ON/OFF 7 80 LEDx12 24VDC 2KG
  • 规格
  • 下载
  • 配件

ET8575

Electrical and Control

Voltage24VDC
Power8W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-40 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X12
Beam Angle120°
Delivered Lumen50lm
Colour RenderingCRI 80
SDCM7
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2 KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8575

文件

ET8575.IES
