ET8585

  • 产品信息

Die casting aluminum body.

Can be selected 316 stainless steel decorative bezel.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Electrostatic powder coating.

The exposed screws are stainless steel.

Strengthened PP mounting sleeve.

Optional anti-glaring louver, The products are suitable for square,

building, sculpture, green belt, trees and other landscape lighting.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET8585 60W 8°/12°/22°/35°/45°/15°*45° 2700K / 3000K / 4000K / 5000K 5039lm（3000K 12°） ON/OFF 5 80 LEDx48 220V-240V 7.8KG
  • 规格
  • 下载
  • 配件

ET8585

Electrical and Control

Voltage220V-240V
Power60W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-30 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X48
Beam Angle120°
Delivered Lumen5039lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight7.8 KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8585
