ET5167

  • 产品信息

Aviation aluminum profile .

Ultra white tempered glass.

Silicone gasket.

Anti-corrosion electrostatic powder coating.

Stainless steel external screws and mounting plate.

On/off standard, DALI , 0-10V or Traic dimming is optional.

No upward lighting, and the lighting distribution evenly throws on the ground.

Adopting a directional multi particle asymmetric reflecting device, resulting inhigher luminous efficiency and wider directional irradiation range.

Modular system, head and pole can be quickly interchanged.

The anchoring devices provided by ET Lighting are all made of SS304 material,

with high strength, corrosion resistance, and long lifetime.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET5167 12W 360° 2700K / 3000K / 4000K 498lm ON/OFF 5 80 SMDx35 180V-264V 5.2Kg
  • 规格
  • 下载
  • 配件

ET5167

Electrical and Control

Voltage180V-264V
Power12W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental                                                                                        -30 °C ~ 50 °C


LED and Optics

LED BrandOSRAM
LED QuantitySMDx35
Beam Angle360°
Delivered Lumen498lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight5.2KG
Warranty3 years
RatingIP65
Impact ProtectionIK08
CertificationsCE



ET5167

ET5167
