ET8833

  • 产品信息

Using a specially designed multiple reflection principle, the light is efficiently emitted in anasymmetric direction to achieve uniform wall cleaning and anti glare effects.

The product is suitable for installation in key lighting applications such as corridors, walls, andsculptures.

Aluminium alloy lamp body.

Stainless steel decorative bezel, 316 stainless steel can be selected.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Surface double electrostatic powder coating..

Special vacuum coating reflector.

Mounting plate and stainless steel external screws.

Strengthened PP mounting sleeve.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET8833 6W Asymmetric 2700K / 3000K / 4000K / 5000K 270lm ON/OFF 3 80 COBx1 220V-240V 1.2KG
  • 规格
  • 下载
  • 配件

ET8833

Electrical and Control

Voltage 220V-240V
Power6W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1.
Beam Angle Asymmetric
Delivered Lumen490lm
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight1.2KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8833

ET8833

可选配件

  • Information
  • Downloads
  • Accessories
  • Service

71 025

DALI cross switch

DALI cross switch
sdsdsds

71 025

DALI cross switch

DALI cross switch
下载

Product data sheet

Product data sheet

The technical specifications in the instructions for use, product data sheets and quotation texts refer to the products manufactured at the time of publication. We are constantly working to improve the performance and efficiency of our products. The goods delivered may therefore deviate slightly from those advertised.
