ET8131

  • 产品信息

This is a compact lighting fixture installed on a paved surface, suitable for both outdoor and indoor use.

The light can be directly illuminated to the road surface, no upward light, no glare, suitable for illuminating roads, paths, steps and some hidden places that need to be illuminated.

Aluminum die-cast lamp body and stainless steel lamp body (ф165mm products).

Aluminum die-cast light cover or stainless steel light cover.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Mounting plate and stainless steel external screws.

Strengthened PP mounting sleeve.

Internal special air blocking waterproof cable.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET8131 11W 90° 2700K / 3000K / 4000K / 5000K 210lm ON/OFF 3 80 COBx1 220V-240V 4.5KG
  • 规格
  • 下载
  • 配件

ET8131

Electrical and Control

Voltage 220V-240V
Power11W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityCOB X 1.
Beam Angle360°
Delivered Lumen210m
Colour RenderingCRI 80
SDCM3
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight4.5KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8131
