ET8844

  • 产品信息

This is a compact lighting fixture installed on a paved surface, suitable for both outdoor and indoor use.

The light can be directly illuminated to the road surface, no upward light, no glare, suitable for illuminating roads, paths, steps and some

hidden places that need to be illuminated.

Stainless steel 304 lamp body and stainless steel 304 cover.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Strengthened PP mounting sleeve.

Internal special air blocking waterproof cable.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET8844 2W 90° 2700K / 3000K / 4000K / 5000K 18lm ON/OFF 5 80 LEDx1 24VDC 0.5KG
  • 规格
  • 下载
  • 配件

ET8844

Electrical and Control

Voltage 24VDC
Power4W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-30 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 1
Beam Angle90°
Delivered Lumen18lm
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 5000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight0.5KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8844
