ET8849

  • 产品信息

Die casting aluminum body.

Ultra white tempered glass.

Silicone gasket.

High efficiency PMMA lens.

Anti-corrosion electrostatic powder coating.

Mounting plate and stainless steel external screws.

Strengthened PP mounting sleeve.

High Power LED chips, constant current driver, line voltage input.

On/off standard, DALI , 0-10V or DMX512 dimming is available.

Specialized anti-water & vapour wiring.

Slip-resistant glass is available for walking area in public.


型号 功率 角度 色温 流明 控制方式 色容差 显色指数 LED 电压 重量
ET8849.N 7W 8°/12°/22°/35°/45°/15°*45° 2700K / 3000K / 4000K / 6000K 501lm（3000K 8°） ON/OFF 5 80 LEDx4 100V-240V 2.6KG
ET8849 7W 8°/12°/22°/35°/45°/15°*45° 2700K / 3000K / 4000K / 6000K 671lm（3000K 8°） ON/OFF 5 80 LEDx6 100V-240V 2.6KG
  • 规格
  • 下载
  • 配件

ET8849.N

Electrical and Control

Voltage 100V-240V
Power7W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 4
Beam Angle8°/12°/22°/35°/45°/15°*45°
Delivered Lumen671lm（3000K 8°）
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 6000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2.6KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8849.N

文件

ET8849.N

可选配件

  • 规格
  • 下载
  • 配件

ET8849

Electrical and Control

Voltage 100V-240V
Power7W
Power SupplyBuilt-in
ControlON/OFF / 0-10V / DALI
Cable0.5M H05RN-F 3x1mm2
Environmental-20 °C ~ 50 °C


LED and Optics

LED BrandCITIZEN / CREE
LED QuantityLED X 6
Beam Angle8°/12°/22°/35°/45°/15°*45°
Delivered Lumen671lm（3000K 8°）
Colour RenderingCRI 80
SDCM5
CCT2700K / 3000K / 4000K / 6000K
LED OpticPMMA Lens


Physical

HousingDie-cast aluminum
Lens MaterialTempered glass
External ScrewStainless steel material
Surface TreatmentAnticorrosive coating
Net Weight2.6KG
Warranty3 years
RatingIP67
Impact ProtectionIK10
CertificationsCE


ET8849

文件

ET8849

可选配件
