Recessed in the ground to reduce the sense of vision but provide lighting at the same time. Various dimensions, powers, optical lenses and anti-glaring accessories, providing a comfortable light distribution.
Die casting aluminum body.
Ultra white tempered glass.
Silicone gasket.
High efficiency PMMA lens.
Anti-corrosion electrostatic powder coating.
Stainless steel external screws and mounting plate.
Strengthened PP mounting sleeve.
Optional anti-glare louver, anti-slip glass, optional 316L stainless steel decorative faceplate. The products are suitable for square, building, sculpture, green belt, trees and other landscape lighting.
| 型号 | 功率 | 角度 | 色温 | 流明 | 控制方式 | 色容差 | 显色指数 | LED | 电压 | 重量 |
|---|---|---|---|---|---|---|---|---|---|---|
| ET8048 | 14W | 8°/12°/22°/35°/45°/15°*45° | 2700K / 3000K / 4000K / 6000K | 1302lm(3000K 8°) | ON/OFF | 5 | 80 | LEDx9 | 220V-240V | 2KG |
Electrical and Control
| Voltage | 220V-240V |
| Power | 14W |
| Power Supply | Built-in |
| Control | ON/OFF / 0-10V / DALI |
| Cable | 0.5M H05RN-F 3x1mm2 |
| Environmental | -20 °C ~ 50 °C |
LED and Optics
| LED Brand | CITIZEN / CREE |
| LED Quantity | LED X9 |
| Beam Angle | 8°/12°/22°/35°/45°/15°*45° |
| Delivered Lumen | 1302lm(3000K 8°) |
| Colour Rendering | CRI 80 |
| SDCM | 5 |
| CCT | 2700K / 3000K / 4000K / 6000K |
| LED Optic | PMMA Lens |
Physical
| Housing | Die-cast aluminum |
| Lens Material | Tempered glass |
| External Screw | Stainless steel material |
| Surface Treatment | Anticorrosive coating |
| Net Weight | 2KG |
| Warranty | 3 years |
| Rating | IP67 |
| Impact Protection | IK10 |
| Certifications | CE |
